| English |
Manuals and Data Sheets |
Français |
| USB422 |
Information sheet on USB-422 Dual RS422 port for DAW's |
USB422 |
| USB422V |
Information sheet on USB-422V Dual RS422 port with GPIO and Bi-level/Tri-Level
Video Reference input |
USB422V |
| USB422 |
Manual for USB-422 Dual RS422 port for DAW's |
| USB422v |
Manual for USB-422v Dual RS422 port for Systems that require Video Sync Input and/or GPIO In/Out (CBServer3/Mosaic) |
| ptcontroller.pdf
(457KB) |
Information sheet on using Protools as a controller to the RM-6 (For example in the Icon)
30 June 2009 |
|
| ptdevice.pdf
(457KB) |
Information sheet on using Protools as a device to the RM-6 (For example as the dubber)
30 June 2009 |
|
| AX24_to_CB_USB422.pdf
(39KB) |
Information sheet on using the USB-422 with the DAD AX24
29 March 2011 |
|
| Windows Test Software |
| usb422.msi |
Windows Test software comprising of a remote control and a virtual machine,record arming commands.
Test panels for USB422V video input and GPIO. Controller now has copy clipboard and locate from clipboard
commands. Now will only open and close ports that are visible (used to enable one port at a time).separate
open/close button on each port
22 Nov 2013
|
| usbtest.zip |
Alternative Windows Test software comprising of a remote control
and a virtual machine,record arming commands. Not as fast but easier to
use
5 Aug 2015
|
| Mac Test Software |
| latency-mac.zip |
S/W to measure the latency of the serial connection |
| serial2x.zip |
Mac Universal binary Test software comprising of a remote control and a virtual machine,record arming commands.
22 March 2009
|
| Windows/Mac/Linux Drivers |
| FTDI VCP Driver Page |
The FT2232 chipset is used, the latest drivers may be found on the FTDI site |
|
| Mavericks/Yosemite |
Use version 2.3 or later, also see the information in 'mac latency.pdf' below on how to disable the apple driver
|
| Mac Lion/Mountain lion |
The disk image includes drivers for Mac OS X 10.3 and for 10.4 to 10.9 (disk image version 2.2.18 or later).
The downloaded disk image contains two installer packages, please
use the package named FTDIUSBSerialDriver_10_4_10_5_10_6_10_7.mpkg.
Usage with OS X Mountain Lion (10.8, and 10.9)
This package can also be installed under OS X Mountain Lion.
If you see a warning during installation that the package has not been purchased from the Appstore and that the developer
cannot be verified, the reason is that the package has not yet been signed by the manufacturer.
You may install the package nonetheless by right clicking on the package (or Ctrl Click).
Then select "Open" from the context menu.
|
| Low Latency Mac Driver |
| mac latency.pdf
(34KB) |
Updated April 6th 2017, Instuctions on installing and setting the
MAC low latency driver including extra procedure required for Mavericks
and Yosemite, El capitan, Sierra and High Sierra
|
Latence avec un Mac |
| MacHighSierra.pdf
(134KB) |
Updated March 28th 2018, Instuctions on disabling SIP on Mac Sierra and High Sierra (Thanks to
Jonathan Martins for the concise information, and to Alicja Golianek for testing on High Sierra)
|
OS Mac Sierra
|
| KextDrop |
Direct link to KextDrop installation program
|
| MacLow2p2p17.kext.zip |
"MacLow2p2p17.kext" Signed 32/64 bit FTDI Driver modified for Low Latency
|
| MacLow2p3.kext.zip |
"MacLow2p3.kext" Signed 64 bit FTDI Driver modified for Low Latency (Yosemite, Mavericks, Sierra, High Sierra)
|
